MAPROCX-Module

MAPROCX Module : MOPv6.0

Mapro CX is a reliable, secure and easy to use fingerprint module utilized for an accurate identification, verification and authentication process of an individual.

Get In Touch Download Brochure

Our MAPROCX Module

Mapro CX captures high-resolution fingerprint images with the most rugged and advanced optical sensor. Our MAPROCX fingerprint module is an advanced capacitive sensor. The module supports MINEX compliance embedded extractor which is a FAP10 compliant fingerprint module.

Parameters Specification
Fingerprint Sensor: Advanced Capacitive Sensor
Spatial Resolution: 500 DPI +/- 5 %
Sensing Area: 16 mm x 18 mm
Image Size: 316 x 354 Pixels
Image Grayscale: 256 (8 - Bit Gray Level)
Image Capture Speed (Continuous): 5 FPS
Maximum Acquisition Time (Placement to Template): < 2 sec
Approx Dimensions (L x W x H): 35 x 24 x 6.5 mm
Approx Weight: 0.007 Kg
Parameters Specification
Operating Voltage: 5V +/- 5% (USB Powered Device)
Operating Current (max): 80 mA
Stand by Current (max): 50 mA
Interface: USB 2.0 / Serial TTL
Parameters Specification
Operating Temperature: 0 to 45 degC
Storage Temperature: 0 to 50 degC
Humidity (Operating / Storage): < 90% RH, Non-condensing
Parameters Specification
Biometric Data Interchange Format: ISO 19794-2 for minutiae & ISO 19794-4 for Image Template
Environmental, Health and Safety: RoHS Certification
BIS: IS 13252 (Part 1)
Safety: IEC60950
EMI / EMC Compliance: CE & FCC Class A
*FBI PIV Certification: Compliance
*STQC Certification: Yes
IP Rating: IP67
Device Driver: WHQL Certified with Unique Serial Number
OS Supports: Win XP, Win 7, Linux (32 bit & 64 bit)
*Applied for certification
